| Model | BC-1930E-HT |
| Printhead Type | EPSON13200-A1 |
| Printhead Quantity | 30 |
| Printing Speed | 1Pass 240*1800DPI 1000m2/H 2Pass 240*3600DPI 500m2/H |
| Color Mode | 4-color: KCMY 6-color: KCMY+FY+FR(Optional) |
| Printing Width | 1900mm |
| Ink Type | Sublimation Ink |
| Transmission Media | Rubber Roller Mode |
| Ink Capacity | 4*20L |
| Printing Media | Sublimation Paper |
| Drying System | External intelligent air-heat integrated dryer |
| Moisturizing Mode | Automatic sealed moisturizing and cleaning |
| RIP Software | Maintop 7.0 |
| PC System | Win 7 64bit , Win 10 64bit |
| File Format | TIF / JPG |
| PC Requirements | Hard disk: 500G/1T, ATI Discrete Graphics 4G RAM, Quad Gigabit Ethernet Port, 16G Memory,Inteleight-core i7 Processor |
| Standard Configuration | Intelligent Drying System; ntegrated three-colour Light Alarming System; Continuous lnk Supply System;10000-meter Take-up System; Negative Pressure System: Magnetic Levitation Technolog |
| Working Condition | Temperature: 22±5°C,Humidity: 50±10% |
| Take Up System | Automatic feeding and collecting system |
| Input Voltage | Printer: AC220V Drying: AC380V(Three-phase, Five-wire) |
| Power Consumption | Printer: 7KW Drying:14.5KW |
| Printer Size | Printer: L4000mm*W1835mm*H1880mm 10000-meter Base: L2600mm*W1065mm*H1120mm |
| Packing Size | Printer:4150mm*1370mm*2140mm 10000-meter Base:2700mm*1100mm*1365mm |
